Description
GET A SHARPER VIEW FROM YOUR CONNECTED HELM
With its sleek design, powerful processing and upgraded IPS display, this advanced 7”, 9”, 12” or 16” chartplotter integrates seamlessly into your Garmin marine system.
Easily integrate with more engines.
Connect to compatible third-party devices with digital switching and OneHelm™ integrations.
Easily build your marine system by using our advanced network connectivity.
Navigate any waters with preloaded Garmin Navionics+™ charts on select models.
See below your boat with built-in sonar capabilities on select models.
Manage your marine experience from nearly anywhere1.
Feature |
Details |
Dimensions |
7.6″ x 5.5″ x 2.9″ (19.2 x 14.0 x 7.4 cm) |
Weight |
2.8 lbs (1.3 kg) |
Water rating |
IPX7 |
Touchscreen |
Yes |
Display Type |
WSVGA |
Display Size |
6.1″ x 3.5″; 7.0″ diagonal (15.4 x 9.1 cm; 17.8 cm diagonal) |
Display Resolution |
1024 x 600 pixels |
Mounting Options |
Bail, flush, or flat (requires professional tools and knowledge for flat mounting) |
Input Method |
Touchscreen |
Data Card Support |
2 microSD cards (back of unit) |
Waypoints |
5,000 |
Track Points |
50,000 |
Tracks |
50 saved tracks |
Navigation Routes |
100 |
GPS |
Yes |
GLONASS |
Yes |
Galileo |
Yes |
Receiver |
Built-in, 10 Hz |
NMEA 2000 Compatible |
Yes |
NMEA 0183 Compatible |
Yes |
Supports WAAS |
Yes |
Built-in Maps |
Tide tables |
Optional Maps |
BlueChart g3, BlueChart g3 Vision, LakeVü g3, LakeVü g3 Ultra, Garmin Navionics+, Garmin Navionics Vision+, TOPO 100K, Standard Mapping, Quickdraw Contours, Raster charts |
Chartplotter Features |
Smart Mode, AIS, DSC, Fusion-Link™, GSD/GCV Black Box Sonar Support, ActiveCaptain®, GRID, Wireless Remote, Sailing, Spoken Audio Alerts, OneHelm Support |
Power Input |
10 to 32 Vdc |
Typical Current Draw |
1.08 A at 12 Vdc |
Maximum Current Draw |
1.45 A at 12 Vdc |
Maximum Power Usage |
17.6 W at 10 Vdc |
Sonar Types |
Traditional, ClearVü, SideVü (requires GCV™ black box, sold separately) |
Connections |
NMEA 2000® (1 port), NMEA 0183 Input (1 Rx), NMEA 0183 Output (1 Tx), Video Input (1 BNC composite), J1939 (1 port), Garmin Marine Network (1 port), USB, ANT+, Bluetooth, Wi-Fi |
